MariaDB + phpmyadmin + Docker - Local DB Setup and Container Import/Export

Introduction

This guide will walk you through setting up MariaDB and phpMyAdmin within Docker containers. We will reuse the folder setup and files from the previous recipe (recipe-02).

You can find the source files for this tutorial in the recipe-03 folder of this repository: https://github.com/ikknd/docker-study

1. Modify docker-compose.yml File

Here's the docker-compose.yml configuration:

version: "3.7"

services:

  web:
    image: nginx:1.17
    ports:
      - 80:80
    volumes:
      - /var/www/docker-study.loc/recipe-03/php:/var/www/myapp
      - /var/www/docker-study.loc/recipe-03/docker/site.conf:/etc/nginx/conf.d/site.conf
    depends_on:
      - php
      - mariadb

  php:
    image: php:7.2-fpm
    volumes:
      - /var/www/docker-study.loc/recipe-03/php:/var/www/myapp
      - /var/www/docker-study.loc/recipe-03/docker/php.ini:/usr/local/etc/php/php.ini
    depends_on:
      - mariadb

  mariadb:
    image: mariadb:10.4
    restart: always
    volumes:
      - mariadb-data:/var/lib/mysql
    environment:
      MYSQL_ROOT_PASSWORD: qwerty

  phpmyadmin:
    image: phpmyadmin/phpmyadmin:latest
    ports:
      - 8000:80
    environment:
      - PMA_ARBITRARY=1
      - PMA_HOST=mariadb
    depends_on:
      - mariadb

volumes:
  mariadb-data:

In this configuration:

• mariadb-data volume: This volume is created to store all database data. Even if the container is restarted, the data will persist.
• MYSQL_ROOT_PASSWORD: qwerty: This environment variable sets the root password for the MariaDB container.
• PMA_ARBITRARY=1: This environment variable adds a "server" input field to the phpMyAdmin login page. This allows you to use phpMyAdmin with external MySQL databases, not just this local setup.
• PMA_HOST=mariadb: This environment variable configures phpMyAdmin to connect to the MariaDB container, which is named mariadb in this docker-compose.yml.
• ports: - 8000:80: This maps port 80 inside the phpmyadmin container to port 8000 on your host machine, making phpMyAdmin accessible via localhost:8000.
• depends_on: This ensures that containers are started in the correct order, preventing a container from starting before the services it depends on are running.

2. Running the Containers

Navigate to the docker/ directory within your project's recipe-03 folder and execute the following command:

docker-compose up -d

After the containers have started:

• You should be able to access the phpinfo page at myapp.loc/.
• You can access phpMyAdmin at myapp.loc:8000. Log in using the credentials:
  • Username: root
  • Password: qwerty

3. Initializing the Database with Data

If you need your database to be up and running with initial data, you can modify the MariaDB service in your docker-compose.yml:

Add the following to the mariadb service:

command: "mysqld --init-file /data/application/init.sql"

And add a volume mapping for your initialization script:

volumes:
  - mariadb-data:/var/lib/mysql
  - ./init.sql:/data/application/init.sql # Add this line

• init.sql: This file should contain your existing database dump.
• Volume Mapping: Using volumes, we copy the init.sql file into the container at /data/application/init.sql.
• mysqld --init-file: This command tells MySQL to start and import the SQL file specified by --init-file during its initialization process.

4. Importing and Exporting Databases

Once your database is running, you can manage your data using docker exec.

First, find the name or ID of your MariaDB container:

docker container ls

This command will list all running containers. Look for the container associated with MariaDB (it might be named something like docker_mariadb_1).

Importing a Database

To import a local database dump into a container, use the following command, replacing docker_mariadb_1, DB_NAME, and your_local_db_dump.sql with your specific details:

docker exec -i docker_mariadb_1 mysql -uroot -pqwerty DB_NAME < your_local_db_dump.sql

• docker exec -i: Executes a command in a running container. The -i flag keeps STDIN open even if not attached.
• docker_mariadb_1: The name or ID of your MariaDB container.
• mysql -uroot -pqwerty DB_NAME: The command to connect to MySQL as root with the password qwerty and select the DB_NAME database.
• < your_local_db_dump.sql: Redirects the content of your local SQL dump file into the mysql command.

Exporting a Database

To export a database from a container to a local file, use this command:

docker exec -i docker_mariadb_1 mysqldump -uroot -pqwerty DB_NAME > your_local_db_dump.sql

• mysqldump -uroot -pqwerty DB_NAME: This command dumps the specified DB_NAME database from the MariaDB container.
• > your_local_db_dump.sql: Redirects the output of mysqldump to a local file named your_local_db_dump.sql.
